Mobile VSI Crusher
Overview of MOBILE VERTICAL SHAFT IMPACT CRUSHER
Mobile VSI Crushers are ideal for tertiary crushing and screening applications in quarrying, mining, concrete recycling, infrastructure and construction industries. It is especially used to process raw material to excellent aggregate and sand for railway, highway, freeway and building construction.
Features of MOBILE VERTICAL SHAFT IMPACT CRUSHER
1. High capacity
2. fine crushing and shape adjusting
3. high performance, flexible
4. integral crushing & screeing
5. belt conveyor self-loaded
Specifications of MOBILE VERTICAL SHAFT IMPACT CRUSHER
-
Mobile Vertical Shaft Impact Crusher
Technical Data//Model Y3S1848V81 Y3S1860V92 Y3S2160V140 Transportation size (mm) 13500×2830×4350 15600×2830×4350 15600×3100×4480 Weight(t) 31 36 49 Tire Configuration Dualaxial Dualaxial Triaxial Vertical Shaft Impact Crusher VSI-8518 VSI-9526 VSI-1140 The Maximum Feeding Size(mm) 35 40 45 Capacity(T/h) 100-260 150-380 225-520 Belt Conveyor Under Vibrating Screen B800×7M B800×8M B1000×8M Self-loaded Belt Conveyor B800×2.2M B800×2.5M B1000×2.5M Vibrating Screen 3YZS1848 3YZS1860 3YZS2160 Electric control standard control box + control panel control box + control panel control box + control panel Optional Control box + LCD Control box + LCD Control box + LCD Hydrau lic leg standard 4 4 4 Optional 2 2 2 Hydraulic cyclinder standard 0 0 0 optional 2 2 2 Note:Any change of technical data shall not be advised additionally.
